APC AP7752 Redundant Automatic Transfer Switch Item # 349890

 |
APC AP7752 Redundant Automatic Transfer Switch
$ 760 .99 / each $760.99
In Stock
Free delivery
Estimated delivery 3-7 business days

    Description

    APC Rack Automatic Transfer Switches (rack ATS) provide reliable, redundant rack mount power to single-corded equipment. The rack ATS has dual input power cords supplying power to the connected load. If the primary power source becomes unavailable, the rack ATS will seamlessly source power from the secondary source without interrupting critical loads. The Rack ATS has built-in network connectivity, which allows for remote management via Web, SNMP, or Telnet interfaces.

    Back To Top

    Product Details

    Item # 349890
    OfficeMax # 23598956
    Manufacturer # T10914
    height 1.7 in
    Certifications & Standards EN 55022 Class A; FCC Part 15 Class A
    Output Voltage 120 V AC Nominal
    width 17 in
    package contents 20A Rack Automatic Transfer Switch; Documentation CD; Installation Guide; Rack Mounting Brackets; RS-232 Configuration Cable; Warranty Card
    depth 9 in
    Product Name 20A Rack Automatic Transfer Switch
    manufacturer American Power Conversion Corp
    Plug/Connector Type NEMA L5-20P
    Input Voltage Range 120 V ACNominal
    weight 10.98 lb
    brand name APC
    frequency 47 to 63 Hz
    Input Connectors 2 x power NEMA L5-20
    Input Voltage 110 V AC
    Current 16 A Derated Input Current; 20 A Line Current Per Phase; 20 A Input Current Per Phase; 20 A Total Current Draw Per Phase
    Receptacles 10 x NEMA 5-20R
    warranty length 2-year limited
    Show More ▾
    Back To Top

      Customer Reviews

      Back To Top

      From the Manufacturer|Powered by Webcollage

      Thank You Is the information in this section helpful? Yes / No

      Overview

      • Power Distribution

        The growing complexity of IT environments, from wiring closets and server rooms to data centers of all sizes, has increased the need for reliable power distribution to the rack level. Eliminating power management issues is essential for IT and Facilities managers to maintain system availability of increasing higher density equipment. Power Distribution Units are an essential element in managing power capacity and functionality for critical network, server and data center equipment.

        APC provides a wide array of power distribution solutions for your IT environment. APCs standardized PDUs are designed to increase the manageability and efficiency of your data center. Power Distribution solutions provide real-time remote load monitoring of connected equipment and individual outlet power control for remote power recycling, manage power-up or power-down sequencing of equipment. IT and Data Center Managers rely on APC PDU alarms to warn of potential power overloads before critical IT failures occur.

      Features

      • Rack-mount Transfer Switches

        Provides redundant rack mount power to single-corded equipment.

        The only manageable transfer switch in 1U
        APC Rack Automatic Transfer Switches (rack ATS) provide reliable, redundant rack mount power to single-corded equipment. The rack ATS has dual input power cords supplying power to the connected load. If the primary power source becomes unavailable, the rack ATS will seamlessly source power from the secondary source without interrupting critical loads. The Rack ATS has built-in network connectivity, which allows for remote management via Web, SNMP, or Telnet interfaces.

      • AP7752 Features

        • Local Current Monitoring Display - The aggregate current draw per rack PDU is displayed on the unit via a digital display. The local digital display helps installers avoid overloaded circuits by providing a visible warning when the current draw is close to the maximum amperage draw of the strip. (Available on designated SKUs only)

        Agility

        • Wide range of input and output connections - Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.

        Availability

        • Remote Management Capabilities - Full-featured network management interfaces that provide standards-based management via Web, SNMP, and Telnet. Allows users to access, configure, and manage units from remote locations to save valuable time. Associated with this feature is the ability to quickly and easily upgrade the firmware via network download to installed units for future product enhancements.
        • Dual Input Power Sources - Supplies redundant AC power to connected equipment. Two AC lines power the unit and if the primary AC power fails, the unit will automatically switch to the alternative power source.

      Images

      {"images":[{"assetWrapper":"image-gallery","runtimeSrc":{"height":2000,"width":2000,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/974893af-41d7-41f8-b320-9e27683d04b1.jpg.web.jpg"},"isAdaCompliant":false,"src":{"height":2000,"width":2000,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/974893af-41d7-41f8-b320-9e27683d04b1.jpg"},"sources":[{"height":960,"width":960,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/974893af-41d7-41f8-b320-9e27683d04b1.jpg.w960.jpg","profile":"W960"},{"height":480,"width":480,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/974893af-41d7-41f8-b320-9e27683d04b1.jpg.w480.jpg","profile":"W480"},{"height":240,"width":240,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/974893af-41d7-41f8-b320-9e27683d04b1.jpg.w240.jpg","profile":"W240"}]},{"assetWrapper":"image-gallery","runtimeSrc":{"height":2000,"width":2000,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/0f58ba53-2345-4f4f-be43-bb8ca0798e0a.jpg.web.jpg"},"isAdaCompliant":false,"src":{"height":2000,"width":2000,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/0f58ba53-2345-4f4f-be43-bb8ca0798e0a.jpg"},"sources":[{"height":960,"width":960,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/0f58ba53-2345-4f4f-be43-bb8ca0798e0a.jpg.w960.jpg","profile":"W960"},{"height":480,"width":480,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/0f58ba53-2345-4f4f-be43-bb8ca0798e0a.jpg.w480.jpg","profile":"W480"},{"height":240,"width":240,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/0f58ba53-2345-4f4f-be43-bb8ca0798e0a.jpg.w240.jpg","profile":"W240"}]},{"assetWrapper":"image-gallery","runtimeSrc":{"height":2000,"width":2000,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/d51e0546-c12b-48d5-ab14-718753767ef3.jpg.web.jpg"},"isAdaCompliant":false,"src":{"height":2000,"width":2000,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/d51e0546-c12b-48d5-ab14-718753767ef3.jpg"},"sources":[{"height":960,"width":960,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/d51e0546-c12b-48d5-ab14-718753767ef3.jpg.w960.jpg","profile":"W960"},{"height":480,"width":480,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/d51e0546-c12b-48d5-ab14-718753767ef3.jpg.w480.jpg","profile":"W480"},{"height":240,"width":240,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/d51e0546-c12b-48d5-ab14-718753767ef3.jpg.w240.jpg","profile":"W240"}]},{"assetWrapper":"image-gallery","runtimeSrc":{"height":2000,"width":2000,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/a8a9e3cc-08c6-4409-beda-32b99b886c42.jpg.web.jpg"},"isAdaCompliant":false,"src":{"height":2000,"width":2000,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/a8a9e3cc-08c6-4409-beda-32b99b886c42.jpg"},"sources":[{"height":960,"width":960,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/a8a9e3cc-08c6-4409-beda-32b99b886c42.jpg.w960.jpg","profile":"W960"},{"height":480,"width":480,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/a8a9e3cc-08c6-4409-beda-32b99b886c42.jpg.w480.jpg","profile":"W480"},{"height":240,"width":240,"src":"/_cp/products/1409936773521/tab-b7e674c1-9bca-47ab-b006-a032ecb7d906/a8a9e3cc-08c6-4409-beda-32b99b886c42.jpg.w240.jpg","profile":"W240"}]}]}

      Technical Specifications



      Output
      Nominal Output Voltage120V
      Maximum Total Current Draw per Phase20A
      Output Connections(10) NEMA 5-20R
      Overload ProtectionNo
      Input
      Nominal Input Voltage100V, 120V
      Input Frequency47 - 63 Hz
      Regulatory Derated Input Current (North America)16A
      Input ConnectionsNEMA 5-20P
      Cord Length8 feet (2.44 meters)
      Number of Power Cords2
      Acceptable Input Voltage100-125 VAC
      Maximum Line Current per phase
      		20A
      Maximum Input Current per phase
      		20A
      Physical
      Net Weight10.95 lbs. (4.98 kg)
      Maximum Height1.72 inches (44 mm)
      Maximum Width17.00 inches (432 mm)
      Maximum Depth9.00 inches (229 mm)
      ColorBlack
      Environmental
      Operating Environment23 - 113 °F (-5 - 45 °C)
      Operating Relative Humidity5 - 95%
      Operating Elevation0-10000 feet (0-3000 meters)
      Storage Temperature-13 - 149 °F (-25 - 65 °C)
      Storage Relative Humidity5 - 95%
      Storage Elevation0-50000 feet (0-15000 meters)
      Conformance
      Regulatory ApprovalsEN 55022 Class A, FCC Part 15 Class A
      Standard Warranty2 years repair or replace
      Sustainable Offer Status
      RoHSCompliant
      REACHREACH: Contains No SVHCs
      Battery DirectiveCompliant
      Battery NotesContains Lithium Coin Cell
